8 Pull out the MAIN and AOUT Assemblies to
front direction and then remove it.
4 Remove the 2 washers and 2 nuts.
(DEC2920, NKX2FNI)
5 Remove the 6 screws.
(PPZ30P080FTB)
6 Remove the 2 screws.
(PMH30P100FTB)
7 Remove the 3 screws.
(BPZ30P080FTB)
MAIN Assy AOUT Assy
CN5403CN5403CN6CN6
PressPress
Screw, Waher and Nut tightening order
g Jumper wires styling
4
8
8
×2×2
6
×2×2
77
×2×2
5
×4×4
5
×2×2
• Rear view
l MAIN AssyAOUT Assy k
1 2 3
l MAIN AssyAOUT Assy k l MAIN AssyAOUT Assy k
12
×2×2
2 4
6
7
1 3 5
