General safety instructions
Warning pictograms - structure
Warning pictograms indicate danger areas on the machine and warn
of residual dangers. Permanent or unexpected dangers exist in these
areas.
A warning pictogram consists of two fields:
Field 1
is a pictogram describing the danger, surrounded by triangular safety
symbol.
Field 2
is a pictogram showing how to avoid the danger.
Warning pictograms - explanation
The column Order number and explanation provides an explanation
of the n
eighbouring warning pictogram. The description of the warning
pictograms is always the same and specifies, in the following order:
1. A description of the danger.
For example: danger of cutting!
2. The consequence of nonobservance of the risk-avoidance in-
structions.
For example: causes serious injuries to fingers or hands.
3. Risk-avoidance instructions.
For example: only touch machine parts when they have come to
a complete standstill.
