Product description
4.6 Rating plate and CE marking
The rating plate specifies:
• Implement ID No.
• Product
• Basic weight kg
• Permissible total weight kg
• Factory
• Model year
• Model year
4.7 Technical data
Cenius
3003 3503 4003
Working width
3000 mm 3500 mm 4000 mm
Transport width
3000 mm 3500 mm 4000 mm
with
Double-disc coulter
3050 mm 3550 mm 4050 mm
Wing coulter
3080 mm 3580 mm 4080 mm
Tine spacing
273 mm 292 mm 308 mm
Number of tines
11 12 13
Number of tine rows
3
Maximum working depth
300 mm
Overload protection of the tines:
Cenius Super
tension spring
Cenius Special
shear bolt
Levelling unit:
• Concave discs
Disc diameter
460
• Alternative spring tines
Working speed
10-15
Total length
3,80
4,25 (with tandem roller)
Attachment category
Category 2 or 3
Diameter ofbolt: Category 3
Centre of gravity distance (d)
1900 mm
• You can find the value for the permissible total weight on the
implement rating plate.
• Weigh the empty implement to determine the basic weight.
32
Cenius 03 BAG0144.5 10.19
