Cleaning, maintenance and repairs
12.6 Replacing discs (workshop work)
Minimum disc diameter: 360 mm.
The discs are replaced
• the machine lifted, headland setting
• discs raised,
• the machine secured against unintentional
lowering
To replace the discs, unscrew the four screw
unions, then retighten them.
12.7 Tine connection
Inspect the bolts of the tine connection for tight-
ness.
Required tightening torque: 410 Nm.
Required tightening torque: 210 Nm.
Cenius 03 BAG0144.5 10.19
73
