5.1 Tines
Cenius Super
protection by two tension springs.
The overload protection, which consists of two
tension springs, allows the tines to give way if an
overload situation occurs.
n the event of extreme overloading, a
shearing bolt additionally protects the
tines.
Cenius Special
load protection by shear bolt.
In the event of an overload, the bolt shears off
(1) and has to be replaced.
Spare shear bolts for tines fastened on the frame
on Cenius Special
The depth of the tines is guided by the roller.
For information on setting the working depth, see
page 60.
Cenius 03 BAG0144.5 10.19
35
