GreenDrill 5.2 on-board computer
54
GreenDrill BAH0054-4 02.13
7.7 On-board computer - installation and connections
7.7.1 On-board computer - installation in the tractor cab
Fasten the bracket (1) in the tractor cab with two
screws.
Bend the bracket so as to provide optimum
reading of the display.
7.7.2 On-board computer - Power supply
Store the spare cable in the cab.
Do not coil up the cable.
Never connect the 12 volt power supply to the cigarette lighter socket.
7.7.2.1 Power supply from the 3-pin tractor standard socket
Connect the power cable (1)
to the on-board computer
to the 3-pin standard socket in the tractor
cab.
