Ambient Weather WS-2000 User Manual

Version 2.12 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 16
No
Description
1
Memory card slot for upgrades and backup data
2
USB port for loading the operating system (not
required by user)
3
Power jack
4
Reset
Figure 16
6. Display Tablet Operation
Note: About This Section. The display tablet includes buttons at the bottom with icons signifying
the menu functions. This manual includes “quick menu boxes” as shown below, signifying how to
access a setting from home screen. For example, to access calibration panel, from the home screen,
press the Set Key three times to view the calibration panel.
“Menu box” example. From the home screen, press the Set Key 3 times to view the calibration panel.
6.1 Initial Display Tablet Operation
Connect the display tablet power jack to AC power with the power adapter. The tablet starts to
receive from the indoor and outdoor transmitters, as shown in Figure 17.

Ambient Weather WS-2000 Specifications

General

Display Type	Color LCD
Connectivity	Wi-Fi
Power Source (Console)	AC Adapter
Transmission Frequency	915 MHz
Data Logging	Yes
Indoor Temperature Range	32°F to 140°F (0°C to 60°C)
Indoor Humidity Range	10% to 99%
Outdoor Humidity Range	10% to 99%
Wind Direction	0° to 360°
UV Index Range	0 to 15
Console Display	Color
Sensors Included	Temperature, Humidity, Wind Speed, Wind Direction, Rainfall, UV, Solar Radiation
Power Source (Sensor Array)	Solar Panel with Battery Backup
Outdoor Sensor Range	Up to 330 feet (100 meters)
Transmission Range	Up to 330 ft (100 m) line of sight
Update Rate	16 seconds
Data Update Interval	16 seconds
Outdoor Temperature Range	-40°F to 140°F (-40°C to 60°C)
Rainfall Accuracy	+/- 5%
Rainfall Range	0 to 393.7 inches (0 to 9999 mm)
Wind Speed Range	0 to 100 mph (0 to 160 km/h)
Solar Radiation Range	0 to 1800 W/m²
