Ambient Weather WS-2000 User Manual

Version 2.12 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 21
6.5.4 Lightning Icon
The lightning icon appears when then Dew Point exceeds 70 ºF, which signifies temperature
and humidity conditions may be possible for lightning storms to form in the area.
6.5.5 PM2.5 Sensor (optional)
An optional PM2.5 sensor is available for the WS-2000. The display shows the current PM2.5
measurement, and the 24-hour running average, which is a better indication of the accumulative effect
of particulates on overall health.
The display features a color-coded icon with the following breakpoints:
AQI Category
Color
Breakpoints
(µg/m
3
)
Good
Green
0.0 – 12.0
Moderate
Yellow
12.1 – 35.4
Unhealthy for
Sensitive Groups
Orange
35.5 – 55.4
Unhealthy
Red
55.5 – 150.4
Very Unhealthy
Purple
150.5 – 250.4
Hazardous
Maroon
250.5 – 500
Figure 21
6.6 History Mode
6.6.1 Min/Max
View high and low records, and clear specific records in the history mode.
View and reset minimum and maximums.

Ambient Weather WS-2000 Specifications

General

Display Type	Color LCD
Connectivity	Wi-Fi
Power Source (Console)	AC Adapter
Transmission Frequency	915 MHz
Data Logging	Yes
Indoor Temperature Range	32°F to 140°F (0°C to 60°C)
Indoor Humidity Range	10% to 99%
Outdoor Humidity Range	10% to 99%
Wind Direction	0° to 360°
UV Index Range	0 to 15
Console Display	Color
Sensors Included	Temperature, Humidity, Wind Speed, Wind Direction, Rainfall, UV, Solar Radiation
Power Source (Sensor Array)	Solar Panel with Battery Backup
Outdoor Sensor Range	Up to 330 feet (100 meters)
Transmission Range	Up to 330 ft (100 m) line of sight
Update Rate	16 seconds
Data Update Interval	16 seconds
Outdoor Temperature Range	-40°F to 140°F (-40°C to 60°C)
Rainfall Accuracy	+/- 5%
Rainfall Range	0 to 393.7 inches (0 to 9999 mm)
Wind Speed Range	0 to 100 mph (0 to 160 km/h)
Solar Radiation Range	0 to 1800 W/m²
