Ambient Weather WS-2000 User Manual

Version 2.12 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 8
Figure 5
5.3.5 Install Batteries
Reference Figure 6. Insert 2 x AA non-rechargeable batteries (not included) into the battery
compartment. The LED indicator on the back of the transmitter will turn on for four seconds, and then
flash once every 16 seconds (the sensor transmission update period).
(a)
(b)
Figure 6
Note: If the LED does not light up, or stays on permanently, make sure the battery polarity is
correct, or the batteries are fresh. Do not install the batteries backwards. You can permanently damage
the thermo-hygrometer.
Note: We recommend lithium batteries for cold weather climates, but alkaline batteries are
sufficient for most climates. We do not recommend rechargeable batteries. They have lower voltages,
do not operate well at wide temperature ranges, and do not last as long, resulting in poorer reception.

Ambient Weather WS-2000 Specifications

General

Display Type	Color LCD
Connectivity	Wi-Fi
Power Source (Console)	AC Adapter
Transmission Frequency	915 MHz
Data Logging	Yes
Indoor Temperature Range	32°F to 140°F (0°C to 60°C)
Indoor Humidity Range	10% to 99%
Outdoor Humidity Range	10% to 99%
Wind Direction	0° to 360°
UV Index Range	0 to 15
Console Display	Color
Sensors Included	Temperature, Humidity, Wind Speed, Wind Direction, Rainfall, UV, Solar Radiation
Power Source (Sensor Array)	Solar Panel with Battery Backup
Outdoor Sensor Range	Up to 330 feet (100 meters)
Transmission Range	Up to 330 ft (100 m) line of sight
Update Rate	16 seconds
Data Update Interval	16 seconds
Outdoor Temperature Range	-40°F to 140°F (-40°C to 60°C)
Rainfall Accuracy	+/- 5%
Rainfall Range	0 to 393.7 inches (0 to 9999 mm)
Wind Speed Range	0 to 100 mph (0 to 160 km/h)
Solar Radiation Range	0 to 1800 W/m²
