3-8 | 3050-SLR Moisture Analyzer



NOTE

The unit is intended to be mounted on a horizontal surface or on a verticle surface

with a junction box. Contact Ametek for custom orientations.

Figure 3-3b.

Flanged Enclosure

Installation Dimensions
