M470039-01 REV-F Page 13
PLW MODEL NUMBER DESCRIPTION
PLW 36K – 400 – 300 E
Model Type Power Rating Voltage Rating Current Rating E-Package Suffix
TABLE 1.1b – PLA GENERAL VOLTAGE AND CURRENT RANGES
Note: √ = Max Voltage & Current Rated Model; Gray Highlight – Available Model Combinations
PLA MODEL NUMBER DESCRIPTION
PLA 5K – 400 – 300 E
Model Type Power Rating Voltage Rating Current Rating E-Package Suffix
FEATURES AND OPTIONS
• Four constant operating modes: Constant current (CC), constant voltage (CV), constant resistance (CR), and
constant current (CP) mode operation.
• Local control and remote programming for pulse amplitude, pulse width, and pulse cycle.
• Trig-In/Trig-Out and measurement functions.
• GPIB, RS-232, Ethernet, and USB interface programming with SCPI command language.
(Ethernet and USB are available as part of the E-Package).
• Front panel control with keypad and rotary encoder (Tune Mode) for accurate setting.
