M470039-01 REV-F Page 70
2) Press the LOCAL key on the front panel, and rotate the encoder to scroll to the “SYSTEM” menu option.
3) Press ENTER to select.
4) Choose “ETHERNET” and Press ENTER to select option.
5) Select “ADDRESS” and press ENTER to select option.
6) jrEnter the IP address obtained from your network administrator and press ENTER.
7) Choose “NETMASK” by rotating the encoder to scroll and press ENTER to select option.
8) Enter the value obtained from your network administrator and press ENTER.
9) Choose “GATEWAY” by rotating the encoder to scroll and press ENTER to select.
10) Enter the default gateway IP address obtained from your network administrator and press ENTER
To Exit, press LOCAL to go back to the start-up screen
The Ethernet Port Number is 3000.
Please contact AMETEK Programmable Power Technical Support for any additional Ethernet Set-up Question.
USB FUNCTION
The eLoad also provides a USB remote interface to connect to your computer. You need to install USB driver
included in a CD-ROM shipped with your eLoad .
After your USB driver is installed, the USB port is converted to a virtual COM port. Refer to the “Verify Installed
USB Driver using Hyper Terminal (Windows XP/2000/98)” section for detailed procedures on how to verify the
USB driver.
Windows XP USB Driver Installation Procedures
Note: You must have administrative privileges to install the USB driver
1) Connect eLoad Unit using USB cable
2) Click on found new hardware bubble (bottom right hand corner of screen)
3) Found New Hardware Wizard installation window will pop up
