SHORT CONTROL
Enables/Disables Short Control.
CROSS MODE
Toggles between Input Off/Input Remain. Input remain will allow input to remain on when switching modes.
CROSS RANGE
Toggles between Input Off/Input Remain. Input remain will allow input to remain on when switching ranges.
TRIGGER SOURCE
Select the trigger source for transient operation. Please refer to the following table for different trigger sources and the
available triggering methods.
TRIGGER
SOURCE
TRIGGER INPUT
EXT_TRG_IN
*TRG
Command
Ethernet
TRIG:IMM
Command
Front
Panel
EXTERNAL
O
X
X
O
O
BUS
X
O
X
O
O
ETHERNET
X
X
O
X
X
HOLD
X
X
X
O
O
TABLE 3.2 TRIGGER INPUT SOURCE
Important Notes:
1. X = Non-functional & O = Functional
2. EXT_TRG_IN & ETHERNET triggers input through the respective interface connections
3. *TRG and TRIG:IMM are SCPI commands
PROTECTION
OV PROTECTION UC PROTECTION
OV DELAY UC DELAY
UV PROTECTION OP PROTECTION
UV DELAY OP DELAY
OC PROTECTION UP PROTECTION
OC DELAY UP DELAY
AMREL eLoad provides programmable OVP/OCP/OPP and UVP/UCP/UPP over-limit and under-limit protection
capabilities. The user can program all the protection values and delay times. Protection will be activated once the
protection mode has been tripped and then shut down the eLoad input. The protection delay setting provides a
programmed delay time to accommodate short duration surges without inadvertently shutting the input off.
Protection Sub-Menu Navigation: Press the "Menu/Local" key then turn the  encoder to select the PROTECTION
function then the "ENTER" key. Turn the  encoder to select the appropriate protection or delay function by pressing
the "ENTER key to display the current value. Press the "ENTER" key to edit or enter the new value then press the
“ENTER” key to confirm entry. Press the “CLEAR” key to exit from the PROTECTION MODE sub-menu.
V-ON (Under Voltage Lockout): To prevent the eLoad from operating under unstable conditions such as voltages
below the minimum operating voltage, the V-On Protection feature can be utilized. The V-On protection will force the
input to remain off until the V-On voltage threshold is exceeded, the purpose is to ensure sufficient voltage is delivered to
the eLOAD for normal operation. When operating under strict turn-on sequences, such as sending power via a power
supply into an eLOAD with the input already turned on, current overshoot, bounce or ringing may occur. As a
