8 17-08-2004 123312 03
Caution – Hot surface
This symbol is engraved in the grid plate.
• Do not touch the grid plate, the well or the insertion
tube as the calibrator is heating up – they may be
very hot.
• Do not touch the tip of the sensor when it is
removed from the insertion tube/well – it may be very
hot.
• Do not touch the handle of the calibrator during use
– it may be very hot.
• Over 100°C/212°F
If the calibrator has been heated up to temperatures
above 100°C/212°F, you must wait until the
instrument reaches a temperature below
100°C/212°F before you switch it off.
Below 0°C/32°F (applies only to the ITC-155 A
model)
If the calibrator has reached a temperature below
0°C/32°F, ice crystals may form on the insertion tube
and the well. This, in turn, may cause verdigris to
form on the material.
To prevent this from happening, simply heat up the
calibrator to 50°C/122°F.
