Features and Specifications Sorensen DCS Series 1kW and 1.2kW Supplies
1-6 M362500-01 Rev K
1.4.4 Mechanical Specifications
Size: 44mm H x 482.6mm W x 508mm D (1.75” H x 19” W x 20” D)
Weight: 8.2 kg (18 lbs)
OUTPUT CONNECTOR
Models DCS-E 8V through DCS 100V
Connector type: Nickel plated copper bus bars.
Approximate dimensions: 1.365" x 0.8" x 0.125"
Distance between positive and negative bus bar centers: 2.2"
Load wiring mounting holes: Two 0.257" diameter holes on 0.5" centers (1/4" hardware)
Two 0.191" diameter holes on 0.4" centers (#10 hardware)
Models DCS-E 150V through DCS 600V
Connector type: Six–pin Amp Universal Mate-N-Lok connector
Chassis mounted parts: Housing: Amp part number 1-480705-0
Pins: Amp part number 350547-1
Mating connector parts: Housing: Amp part number 1-480704-0
Socket pins: Amp part number 350550-1
Note: Six Socket pins and one mating connector housing are supplied with each 150V through
600V unit.
INPUT CONNECTOR
2 position terminal block plus safety ground screw.
Note: Input power cord not supplied.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
