Sorensen DCS Series 1kW and 1.2kW Supplies Installation and Operation
M362500-01 Rev K 2-5
2.4 Controls, Connectors, and Indicators
Refer to Figure 2-1 and the descriptions below.
2.4.1 Front Panel
(1) AC Power Switch
(2) AC Input Circuit Breaker
(3) OVP Adjust Potentiometer: Manual adjustment for OVP trip level
(4) OVP LED: Indicates that the OVP circuit has been activated when illuminated
(5) Shutdown LED: Indicates activation of the remote shutdown circuit when illuminated
(6) Remote Programming LED: Indicates operation by remote programming when illuminated
(7) Over-Temperature LED: Indicates that the power supply is shut down due to an internal
over-temperature condition when illuminated
(8) Voltage Mode LED: Indicates operation in voltage mode when illuminated
(9) Output Voltage Control: Multi-turn potentiometer used to adjust the output voltage in local
mode
(10) Current Mode LED: Indicates operation in current mode when illuminated
(11) Output Current Control: Multi-turn potentiometer used to adjust the output current limit in
local mode
(12) Digital Voltmeter
(13) Digital Ammeter
2.4.2 Rear Panel
(14) Positive Output for 8, 10, 20, 33, 40, 50, 60, 80, and 100 volt models
(15) Output and Sense Connector for 150, 300 and 600 volt models
(16) Negative Output for 8, 10, 20, 33, 40, 50, 60, 80, and 100 volt models
(17) Programming, Sense and Monitor Connector J3: Input connector for programming signals.
Also provides access to sense connections and monitoring points. See Section 2.4.3 for
individual pin descriptions. Note: The positive output and positive sense are not available
at connector J3 on 150, 300, and 600 volt models.
(18) AC Input Safety Ground Screw
(19) AC Input Connector
