Parts Lists Sorensen DCS Series 1kW and 1.2kW Supplies
5-4 M362500-01 Rev K
Model
Final
Assembly
Mother PCB
Assembly
Front Panel
PCB
Assembly
Output PCB
Assembly
Rectifier
PCB
Assembly
DCS8-140E
5362500-008 5362462-008 5360801-01 1066830-008 N/A
DCS10-120E
5362500-010 5362462-010 5360801-01 1066830-008 N/A
DCS20-60E
5362500-020 5362462-020 5360801-02 1066830-020 N/A
DCS33-36E
5362500-033 5362462-033 5360801-02 1066830-01 5360726-01
DCS40-30E
5362500-040 5362462-040 5360801-02 1066830-01 5360726-02
DCS50-24E
5362500-050 5362462-050 5360801-02 1066830-01 5360726-02
DCS60-20E
5362500-060 5362462-060 5360801-02 1066830-01 5360726-03
DCS80-15E
5362500-080 5362462-080 5360801-02 1066830-080 5360726-04
DCS100-12E
5362500-100 5362462-100 5360801-02 1066830-100 5360726-04
DCS150-8E
5362500-150 5362462-150 5360801-01 N/A N/A
DCS300-4E
5362500-300 5362462-300 5360801-01 N/A N/A
DCS600-2E
5362500-600 5362462-600 5360801-01 N/A N/A
Table 5–4 DCS 1.2kW Parts Lists by Model Number
