Parts Lists Sorensen DCS Series 1kW and 1.2kW Supplies
5-2 M362500-01 Rev K
5.3 Parts Lists
Table 5–1 provides fuse ratings for the DCS 1kW and DCS 1.2kW power supplies.
Table 5–2 provides a matrix of parts lists according to model numbers for the DCS 1kW power
supplies, and Table 5–3 provides a listing of the parts lists.
Table 5–4 provides a matrix of parts lists according to model numbers for the DCS 1.2 kW
power supplies, and Table 5–5 provides a listing of the parts lists.
Reference
Designator
Fuse Type Rating Size
F1 Fast Acting, GBB 25A, 250V 1/4" x 1-1/4"
F2 Time Lag, 3AG 0.5A, 250V 1/4" x 1-1/4"
F3 Fast Acting 10A, 250V 13/32" x 1-1/2"
Table 5–1 DCS 1kW and 1.2kW Fuse Ratings
Model
Final
Assembly
Mother PCB
Assembly
Front Panel
PCB
Assembly
Output PCB
Assembly
Rectifier
PCB
Assembly
DCS8-125E
5360800-01 5362100-008 5360801-01 1066830-008 N/A
DCS10-100E
5360800-12 5362100-010 5360801-01 1066830-008 N/A
DCS20-50E
5360800-02 5362100-020 5360801-02 1066830-020 N/A
DCS33-33E
5360800-03 5362100-033 5360801-02 1066830-01 5360726-01
DCS40-25E
5360800-04 5362100-040 5360801-02 1066830-01 5360726-02
DCS50-20E
5360800-10 5362100-050 5360801-02 1066830-01 5360726-02
DCS60-18E
5360800-05 5362100-060 5360801-02 1066830-01 5360726-03
DCS80-13E
5360800-06 5362100-080 5360801-02 1066830-080 5360726-04
DCS100-10E
5360800-13 5362100-100 5360801-02 1066830-100 5360726-04
DCS150-7E
5360800-07 5362100-150 5360801-01 N/A N/A
DCS300-3.5E
5360800-08 5362100-300 5360801-01 N/A N/A
DCS600-1.7E
5360800-09 5362100-600 5360801-01 N/A N/A
Table 5–2 DCS 1kW Parts Lists by Model Number
