AMF 90XLi - POSITIVE BALL LIFT OPERATION & ADJUSTMENT

SECTION 2.0
Operation & Adjustment
400-088-011 Page 2-1 Rev. Date 10/04
2.0 POSITIVE BALL LIFT OPERATION & ADJUSTMENT
Figure 2-1
Ball Lift Assembly
Track Rail Assembly
Belt Tensioner
Belt Tightener
Ratchet Drive
Assembly
Light Ball
Sensor
PBL ASSEMBLED (REVISED)
