AMF 90XLi - Ball fails to roll up track rails

SECTION 4.0
Troubleshooting
400-088-011 Page 4-3 Rev. Date 10/04
4.3 PROBLEM: Ball fails to roll up track rails.
Reset lift arm height.
Reset lift arm height.
Reset sensor travel.
YES
Replace rod ends.
Replace crank assembly.
YES
START
Ball lift assembly
position too high?
Lift arm sticks in
raised position?
Ball spins on
lower track cover
section?
Ball bounces on
lift arm?
Lift arm does not
engage ratchet
clutch?
Adjust height of rubber
stops as required to obtain
proper ball lift height.
Replace
polyurethane tube.
NO
NO
NO
NO
YES
YES
YES
Oil and dirt
buildup?
Clean track rail and PBL
belt.
NO
YES
