AMF 90XLi - Ball fails to continue to top of lift assembly and stops or slides back to the lift arm

AMF 90XLi PINSPOTTER
400-088-011 Page 4-4 Rev. 10/04
4.4 PROBLEM: Ball fails to continue to top of lift assembly and
stops or slides back to the lift arm.
Lower track cover
worn?
Replace lower
track cover.
NO
YES
NO
Ball lift belt too
loose?
Adjust lift spring
tension.
YES
Lift belt is dirty or
oily?
Clean ball lift belt.
START
YES
Ball lift too far to
rear?
Adjust lift at both
adjustable shafts to
move lift forward.
NO
YES
Adjust upper tension
bracket.
