SECTION 3.0
Lubrication
400-088-011 Page 3-1 Rev. Date 10/04
3.0 LUBRICATION INSTRUCTIONS
3.1 LUBRICATION
Lubrication is one of the most important items in the proper operation and maintenance
of the Positive Ball Lift. Care must be taken to insure that lubricants are applied
correctly. Avoid excessive lubrication to minimize the possibility of transmitting
lubricants to the bowler. Before lubrication of exposed parts or surfaces, it is important
that the old lubricant first be removed. It is also very important to clean the ball lift as
you lubricate.
This section of the manual shows the points of lubrication, the correct lubricants to use,
and the frequency of lubrication for each part of the ball lift.
3.2 LUBRICANT SYMBOLS
OILING: Items indicated by a number within a square require oiling. Use SAE #10
oil as the lubricant.
GREASING: Items indicated by a number within a circle require greasing. Use a
multi-purpose grease (Bearing Guard #2) as the lubricant.
1
1
