AMF 90XLi PINSPOTTER
400-088-011 Page 4-8 Rev. 10/04
4.8 PROBLEM: Rudder slaps ball back onto carpet.
Increase compression of
spring by placing a
retainer ring between the
D-washer & retainer ring
at the lower end of the
weldment.
START
Rudder cams fail to
reset to proper height?
Sensor oily or dirty and
needs adjusting?
Ball lift assembly too
low?
Trip cam followers fail
to hold position when
actuated?
Rudder cams fail to
clear top of 1-inch
diameter follower?
Reset rudder
cams.
Remove washers from
under 1-inch diameter
cam follower.
Adjust height of rubber
stops as required to
obtain proper ball lift
hei
g
ht.
Disassemble, clean and
replace (do not
lubricate). Readjust.
NO
NO
NO
NO
YES
YES
YES
YES
YES
