AMF 90XLi - PBL Light Ball Sensor Assembly (Continued)

AMF 90XLi PINSPOTTER
400-088-011 Page 5-17 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
47 1 070-011-100 CAM SENSOR WELDMENT
47A 1 070-011-110 CAM SENSOR ASSY
(
includes 33 & 47
)
48 1 070-011-099 CAM
49 4 900-208-161 FLANGED BEARING, .503 X .875
50 1 see 50A RUDDER CAM, L.H.
50A 1 070-011-407 RUDDER CAM ASSY, L.H.
(
incl. 28, 49 & 50
)
51 1 809-865-405 SCREW, HEX, 3/8 - 16 X 2½
52 1 070-011-121 PLUG
53 2 948-767-132 WASHER, FLAT, 13/16 X 13/32 X 1/16
54 1 844-065-002 NUT, FLEX LOCK, 3/8 - 16
55 1 070-011-122 RUDDER ARM
56 1 907-000-900 KEY
57 1 831-573-002 NUT, HEX, 1/2 - 13
58 1 000-024-616 CLAMP STUD
59 4 900-212-201 FLANGED BEARING, .753 X 1 X 1.25
60 1 000-024-615 SHAFT
61 1 070-011-079 RUDDER DRIVE WELDMENT
61A 1 070-011-080 RUDDER DRIVE ASSY
(
incl. 33, 59 & 61
)
62 2 070-011-151 SPACER
63 1 070-011-225 CRANK ADJUSTMENT PLATE WELDMENT
64 1 809-865-165 SCREW, HEX, 3/8 - 16 X 1
PBL LIGHT BALL SENSOR ASSEMBLY
(
continued
)
