AMF 90XLi - Ball lift belt leaves V-groove of sheaves

SECTION 4.0
Troubleshooting
400-088-011 Page 4-7 Rev. Date 10/04
4.7 PROBLEM: Ball lift belt leaves V-groove of sheaves.
START
Ball lift assembly not
centered between
track rails?
Center ball lift
assembly at both top
and bottom of track
rail assembly.
Insufficient belt
tension?
Adjust length of ball
lift spring.
NO
YES
YES
Ball lift belt worn? Replace Belt.
NO
YES
