AMF 90XLi - Sensor fails to clear pin jams

SECTION 4.0
Troubleshooting
400-088-011 Page 4-9 Rev. Date 10/04
4.9 PROBLEM: Sensor fails to clear pin jams.
START
Rudder cams fail to
engage 1-inch
diameter follower?
Excessive rudder cam-
to-top-of-cam follower
clearance?
Sensor assembly is
oily?
Sensor spring is too
weak?
Reset trip cam.
Replace sensor
spring.
Add washers under
1-inch diameter cam
follower.
Remove sensor assembly,
disassemble, clean, and
replace. (Do not lubricate.)
NO
NO
NO
YES
YES
YES
YES
