AMF 90XLi PINSPOTTER
400-088-011 Page 5-3 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 3 000-024-673 SPRING 27 1 070-011-035 STRAP
2 2 090-004-520 V- BELT, CARPET DRIVE 28 1 070-011-039 RATCHET ASSEMBLY
3 6 831-565-002 NUT, HEX, 3/8 - 16 29 1 070-011-064 V- BELT, RATCHET DRIVE
4 6 000-024-610 CLAMP STUD 30 1 090-002-016 SPRING EXTENSION
5 1 070-011-052 BALL LIFT ASSEMBLY
see next illustration
31 1 070-011-810 BELT TIGHTENER
6 1 000-021-813 WIPER SUPPORT 32 2 000-026-031 SPRING
7 1 070-004-669 BALL WIPER CLOTH 33 1 070-011-034 EXTENSION ROD
8 2 000-021-814 WIPER CLOTH RING
9 1 000-029-629 DOWN SWEEP WELDMENT
10 1 070-004-670 DUST TRAP
11 4 070-004-654 TRACK SUPPORT BRACKET
12 8 809-865-285 SCREW, HEX, 3/8 - 16 X 1-3/4
13 74 948-767-132 WASHER, 13/32 X 13/16 X 1/16
14 20 844-065-002 NUT, STOVER LOCK, 3/8 - 16
15 1 088-001-235 TRACK RAIL ASSEMBLY
16 4 070-008-212 SPACER
17 1 070-008-207 RAIL WELDMENT
18 1 070-011-148 V- BELT, PADDLE DRIVE, UPPER
19 1 090-002-015 BELT TENSIONER ASSEMBLY
20 1 070-011-178 CRANK ASSEMBLY
21 1 070-011-147 V- BELT, PADDLE DRIVE, LOWER
22 1 070-011-120 LIGHT BALL SENSOR ASSEMBLY
23 12 809-857-165 SCREW, HEX, 5/16 - 18 X 1
24 8 948-761-112 WASHER, 11/32 X 11/16 X 1/16
25 12 844-057-002 NUT, STOVER LOCK, 5/16 - 18
26 14 000-029-910 SHIM
POSITIVE BALL LIFT (PBL) - ASSEMBLED
