AMF 90XLi PINSPOTTER
400-088-011 Page 5-5 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 4 840-057-002 NUT, STOVER LOCK, 5/16 20 1 070-001-995 UPPER YOKE w/NUT
2 4 948-761-112 WASHER, FLAT, 11/32 X 11/16 X 1/16 21 2 000-024-661 PULLEY
*3 2 070-006-320 SHAFT ASSY. ADJ. 9 ½ “ - 11 “ SPACING 22 4 806-265-160 SETSCREW, 3/8 - 16 X 1
2 070-006-329 SHAFT ASSY ADJ. 11“ - “12-5/8” SPACING 23 4 070-006-748 SPACER
2 070-006-333 SHAFT ASSY. ADJ. 12-5/8“ - 14” SPACING 24 4 610-905-704 BALL BEARING
*4 2 070-005-325 SHAFT ASSY. FXD. 9 ½ “ - 11” SPACING 25 1 610-900-711 UPPER SHAFT
2 070-006-328 SHAFT ASSY. FXD. 11” - “12-5/8” SPACING 26 4 951-164-002 WASHER, SPLIT LOCK, 3/8
2 070-006-330 SHAFT ASSY. FXD. 12-5/8“ - 14” SPACING 27 2 809-865-165 SCREW, HEX, 3/8 -16 X 1
5 1 070-011-289 SHOCK ABSORBER BRACKET 28 1 000-029-613 RAIL
6 2 900-112-203 SLEEVE BEARING, .753 X 1-1/4 29 1 088-001-233 BELT, NO-SLIP, V-GUIDE, FLAT
7 1 070-011-002 LOWER SUPPORT 30 1 see 30A IDLER PULLEY
8 2 919-005-800 RETAINING RING 30A 1 000-021-408 IDLER PULLEY ASSY
(
includes 30 & 43
)
9 2 see 9A & 9A1 LINK 31 1 070-008-218 SPACER, LONG
9A 1 000-024-720 LINK ASSY, UPPER
(
includes 6, 9, 10, & 51
)
32 1 000-029-660 SHAFT
9A1 1 000-024-651 LINK ASSY, LOWER
(
includes: 9, 10 & 37
)
33 2 919-005-600 RETAINING RING
10 4 900-110-121 SLEEVE BEARING, .628 X 3/4 34 2 948-983-212 WASHER, FLAT, 1-5/16 X 21/32 X .093
11 4 807-265-060 SETSCREW, 3/8 - 16 X 3/8 35 1 839-549-002 NUT, FLEX LOCK, ¼ - 20
12 1 000-024-606 UPPER SUPPORT 36 2 900-212-161 FLANGED BEARING, .753 X 1.003 X 1
13 16 937-000-000 RIVET, STEEL, 1/4 X 11/32 37 2 900-112-161 SLEEVE BEARING, .753 X 1
14 1 710-501-007 GREASE FITTING 38 1 070-011-040 RATCHET ROLLER
15 1 000-024-647 ROLLER 39 1 809-865-445 SCREW, HEX, 3/8 - 16 X 2¾
15A 1 000-024-650 ROLLER ASSEMBLY
(
includes 15 & 16
)
40 1 919-005-200 RETAINING RING
16 1 900-206-081 FLANGED BEARING, .378 X .688 X 1/2 41 1 070-008-215 BELT TIGHTENER WELDMENT
17 4 856-070-002 NUT, FLANGED, 7/16 - 20 41A 1 070-011-041 BELT TIGHTENER WELDMENT ASSEMBLY
18 1 000-024-607 TUBE
(includes 36 & 41)
18A 1 070-011-004 TUBE & SUPPORT ASSY
(
incl. 7, 12, 13, & 18
)
41A1 1 070-011-042 BELT TIGHTENER ASSEMBL
Y
(
includes 30A,
19 1 000-024-648 PIVOT PIN
31, 35, 38, 40, 41A, 42, 44, 49, & 50)
* Items 3 & 4 vary in length according to the space between the right and left pinspotters.
POSITIVE BALL LIFT (PBL) – EXPLODED VIEW
