AMF 90XLi PINSPOTTER
400-088-011 Page 5-9 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 1 000-029-605 PIVOT SHAFT
2 6 900-110-081 SLEEVE BEARING, .628 X .878 X .5
3 2 see 3A HANGER ARM
3A 2 000-029-659 HANGER ARM ASSY
includes items 2 & 3
4 4 919-005-600 RETAINING RING
5 1 000-029-606 PIVOT SHAFT, SHORT
6 1 070-011-147 V-BELT, PADDLE DRIVE, LOWER
7 1 919-005-500 RETAINING RING
8 2 900-208-120 BEARING
9 1 070-011-131 PULLEY WELDMENT
10 1 000-027-264 SPACER
11 1 090-002-016 SPRING EXTENSION
12 1 090-002-014 SHAFT
13 1 919-005-900 RETAINING RING
14 1 000-026-031 SPRING
PBL BELT TENSIONER ASSEMBLY
