AMF 90XLi - Page 53

AMF 90XLi PINSPOTTER
400-088-011 Page 5-11 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 1 see 1A & 1A1 ARM ASSY WELDMENT, L.H. MACHINE
1A 1 070-011-530 ARM ASSY, L.H. MACHINE
(
includes 1 & 3
)
1A1 1 070-011-524 BELT TIGHTENER, L.H. MACHINE
(
includes
1, 3, 4, 5, 6, 7, 8, & 10)
2 1 see 2A & 2A1 ARM ASSY WELDMENT, R.H. MACHINE
2A 1 070-011-527 ARM ASSY, R.H. MACHINE (includes 2 & 3)
2A1 1 070-011-523 BELT TIGHTENER, R.H. MACHINE (includes
2, 3, 4, 5, 6, 7, 8, & 10)
3 4 900-112-121 SLEEVE BEARING, .753 X .75
4 2 701-316-041 THRUST BEARING, .51 X 1 X 1/16
5 4 900-208-161 FLANGED BEARING, .503 X .875
6 2 see 6A IDLER PULLEY
6A 2 000-021-408 IDLER PULLEY ASSY (includes 5 & 6)
7 4 948-975-172 WASHER, FLAT, 1-1/16 X 17/32 X 3/32
8 4 963-600-002 X-WASHER, 1/4
9 2 919-005-800 RETAINING RING
10 2 070-011-526 IDLER SHEAVE
10A 2 070-011-525 IDLER SHEAVE ASSY (includes 5 & 10)
11 1 000-029-603 SHAFT
PBL BELT TIGHTENER ASSEMBLY
