AMF 90XLi PINSPOTTER
400-088-011 Page 5-13 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 1 919-005-600 RETAINING RING 25 1 070-011-029 NUT
2 1 070-011-028 WASHER 26 1 070-011-064 V-BELT, RATCHET DRIVE
3 1 070-011-027 SHAFT 27 0-26* 948-767-132 WASHER, FLAT, 13/32 X 13/16 X 1/16
4 1 907-000-200 KEY 28 2 070-008-212 SPACER
5 2 900-212-161 FLANGED BEARING, .753 X 1.003 X 1 29 2 948-761-112 WASHER, FLAT, 11/32 X 11/16 X 1/16
6 1 070-011-009 BEARING HOUSING WELDMENT 30 2 844-057-002 NUT, STOVER LOCK, 5/16 - 18
6A 1 070-011-036 BEARING & HOUSING ASSY
includes 5 & 6
7 16 839-549-002 NUT, FLEX LOCK, ¼ - 20
8 1 070-011-033 PULLEY
9 32 000-026-865 WASHER
10 16 070-011-030 ROLLER
11 16 070-011-031 ROLLER SPACER
12 16 809-849-205 SCREW, HEX, ¼ - 20 X 1¼
13 2 919-000-600 RETAINING RING
14 2 000-024-679 BALL BEARING, .625 X 1.375
15 1 070-011-013 CRANK WELDMENT
15A 1 070-011-037 CRANK ASSY
includes 13, 14, 15, & 16
16 1 070-006-142 BUMPER
17 3 919-005-200 RETAINING RING
18 3 070-011-040 RATCHET ROLLER
19 1 070-011-217 RATCHET ARM WELDMENT
20 1 838-866-002 NUT, HEX LOCK, 3/8 - 24, THIN
21 1 947-356-617 WASHER, 5/16
22 1 809-965-125 SCREW, HEX, 3/8 - 16 X ¾
23 1 948-964-142 WASHER, FLAT, .375 X .875 X .094
24 1 070-011-032 SPRING
* The number of washers used depends on the spacing between the left and right machines’ kickplates. See installation drawing 610-007-043.
PBL RATCHET DRIVE ASSEMBLY
To Next Page
