AMF 90XLi PINSPOTTER
400-088-011 Page 5-15 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 4 809-857-165 SCREW, HEX, 5/16 - 18 X 1 23 1 070-011-146 PADDLE
2 2 000-022-869 WASHER 24 2 000-021-423 COLLAR WITH SETSCREW
3 1 070-011-418 TRIP CAM 25 2 000-021-427 FLANGED BEARING, .629 X .878 X 1/8
4 1 070-006-728 CAM FOLLOWER 26 1 000-027-264 SPACER
5 4 949-100-002 WASHER, FLAT, 59/64 X 13/32 X 1/16 27 1 see 27A RUDDER CAM, R.H.
6 1 070-011-068 LINK WELDMENT 27A 1 070-011-406 RUDDER CAM ASSY, R.H.
(
incl. 27, 28 & 49
)
7 1 809-865-205 SCREW, HEX, 3/8 - 16 X 1¼ 28 2 913-448-120 SPRING PIN, ¼ X ¾
8 2 070-011-107 TRIP ARM
(
RESET CAM
)
29 1 070-011-098 SLEEVE
9 1 802-865-996 SCREW, HEX, 3/8 - 16 X 9½ 30 3 919-005-200 RETAINING RING
10 3 000-029-611 WASHER, UNIBALL BEARING 31 2 070-011-626 TRIP ARM ASSEMBLY
11 1 840-065-002 NUT, FLEX LOCK, 3/8 -16, THIN 32 2 070-011-273 TAB
12 1 090-005-258 ROD ASSEMBLY 33 6 900-208-091 FLANGED BEARING, .503 X .690 X 9/16
13 1 838-866-002 NUT, HEX LOCK, 3/8 - 24 34 2 722-985-512 COMPRESSION SPRING
14 2 070-011-096 ROLLER 35 2 900-205-081 FLANGED BEARING, .315 X .44 X 1/2
14A 2 070-011-105 ROLLER ASSEMBLY
(
includes 14 & 35
)
36 1 809-857-880 SCREW, HEX, 5/16 - 18 X 5-1/2
15 2 070-011-077 TRIP FINGER 37 2 090-007-276 BRACKET
16 2 722-971-522 COMPRESSION SPRING 38 1 070-011-040 RATCHET ROLLER
17 4 844-057-002 NUT, STOVER LOCK, 5/16 - 18 39 1 844-070-002 NUT, STOVER LOCK, 7/16 - 20
18 3 948-761-112 WASHER, 11/16 X11/32 X 1/16 40 3 070-011-108 WASHER
19 1 070-011-097 CRANK PULLEY 41 3 919-005-500 RETAINING RING
19A 1 070-011-178 RUDDER DRIVE CRANK ASSY
(
includes 42 1 000-026-031 SPRING
13, 17, 18, 19, 20 & 63)
43 2 809-849-125 SCREW, HEX, ¼ - 20 x ¾
20 1 070-011-092 CRANK SHAFT WELDMENT 44 1 070-011-299 SENSOR BRACE
21 1 000-029-697 ADJUSTMENT TUBE 45 2 844-049-002 NUT, STOVER LOCK, ¼ - 20
21A 1 000-029-696 ADJUSTMENT TUBE ASSY
(
includes 21 & 25
)
46 1 070-011-067 RUDDER ARM SUPPORT
22 1 070-011-148 V-BELT, PADDLE DRIVE, UPPER 46A 1 070-011-066 RUDDER ARM SUPPORT ASSY
(
incl. 46 & 59
)
PBL LIGHT BALL SENSOR ASSEMBLY
