AMF 90XLi PINSPOTTER
400-088-011 Page 5-19 Rev. Date 10/04
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 2 809-865-165 SCREW, HEX, 3/8 - 16 X 1
2 2 951-164-002 WASHER, SPLIT LOCK, 3/8
3 1 000-021-813 WIPER SUPPORT
4 2 088-001-232 RAIL COVER, BLACK
5 2 000-024-666 TRACK RAIL WELDMENT
6 2 088-001-231 RAIL COVER, CLEAR
7 2 088-001-230 THIMBLE
8 2 810-365-401 SCREW, SOCKET HEAD CAP, 3/8 - 16 X 2-1/2
9 1 070-011-063 SHAFT
10 2 844-065-002 NUT, STOVER LOCK, 3/8 - 16
11 2 844-057-002 NUT, STOVER LOCK, 5/16 - 18
12 0-22*** 948-767-132 WASHER, FLAT, 13/32 X 13/16 X 1/16
13 2 900-210-161 FLANGED BEARING, .628 x 1
14 1 070-011-411 LIFT ARM WELDMENT
14A 1 070-011-412 LIFT ARM ASSEMBLY
includes 13 & 14
14A1 1 070-011-413 LIFT ASSEMBLY
incl. 9, 10, 14A, 15, 20 & 22
15 4 090-002-024 CRADLE LINER
16 1 838-866-002 NUT, HEX, 3/8 - 24
17 1 090-005-259 ROD ASSEMBLY
18 1 070-011-218 LEVER ARM WELDMENT
19 2 808-857-280 SCREW, FLAT HEAD, 5/16 - 18 x 1-3/4
20 1 809-865-992 SCREW, HEX, 3/8 - 16 X 9
21 1 958-584-002 WASHER, LOCK, 3/8
22 1 070-008-191 BALL LIFT BRACKET
23 1 000-024-668 TRACK SUPPORT BRACKET WELDMENT
***From 0 to 22 washers may be needed for spacing. See installation drawing 610-007-043.
PBL TRACK RAIL ASSEMBLY
