Axpert-Eazy AC Variable Frequency Drive
6-87
6
Fig. External brake sequence example
C323: Static Pot Option During Stop
This parameter provides selection of the static pot speed at stop to the user.
The following options are
=1: Last Speed
=2: Min Frequency
=3: Max Frequency
=4: A101 Set Freq
=5: B401 Preset speed-1
C324: Panel Temperature Limit
This parameter is set limit for panel temperature fault.
This fault Indicate that the panel inside temperature > C324. Fault will be reset if panel inside
temperature < C324 – 5 °C. This fault is applicable for IU/DU system.
GROUP – 4: SERIAL COMMUNICATION
C401: Baud Rate (bps)
Drive is facilitating with serial communication between drive unit and computer terminal. To control or
monitor single/ multiple units from single computer terminal, serial link can be used. This parameter
defines Baud rate (number of signal transition per second, it can be number of bits per second). The
available options are as under. Option-4 is set as default baud rate.
1: 1200 bps 4: 9600 bps
2: 2400 bps 5: 19200 bps
3: 4800 bps 6: 38400 bps
Refer the detail manual for the ModBus protocol and other information.
C402: Station Number
This parameter defines the address of the unit when connected to the serial network. This AC DRIVE
supports the ModBus protocol. The station number can be assigned to 1 ~ 247.
C403: Parity
