Axpert-Eazy AC Variable Frequency Drive
6-95
6
GROUP – 7: PLC PANEL PARAMETER
C701 to C702: PLC Panel Par1 to 2
This PLC panel parameter 1 & 2 are used in-built PLC for Timer 1 application. Related memory
location of this parameter is from 101 to 102.
C703 to C704: PLC Panel Par3 to 4
This PLC panel parameter 3 & 4 are used in-built PLC for Timer 2 application. Related memory
location from of this parameter is 103 to 104.
C705 to C706: PLC Panel Par5 to 6
This PLC panel parameter 5 & 6 are used in-built PLC for Timer 3 application. Related memory
location from of this parameter is 105 to 106.
C707 to C708: PLC Panel Par7 to 8
This PLC panel parameter 7 & 8 are used in-built PLC for Timer 4 application. Related memory
location from of this parameter is 107 to 108.
C709 to C712: PLC Panel Par9 to 12
PLC panel parameter 9 to 12 can be input and used in-built PLC application. Related memory location
of this parameter is from 109 to 112.
