Example,
READ_ PSI Fn PSIm
Where,
Fn = Flag number (0 to 99)
PSIm = PSI number (1 to 8)
READ PSI
FLAG NO
PSI SELECTABLE OPTIONS
(C101 to C106 and C114 to C115)
BIT STATUS OF FLAG
28: PLC I/P 1
29: PLC I/P 2
30: PLC I/P 3
31: PLC I/P 4
32: PLC I/P 5
33: PLC I/P 6
34: PLC I/P 7
35: PLC I/P 8
44. WRITE_PSI (OPCODE
048)
This command is use to Activate PSI terminal function from In-built PLC.
PSI terminal have selectable options for PLC.
Example,
WRITE_PSI PSIFunction (m) Fn
Where,
Fn = Flag number (0 to 99)
PSI Function (m) = PSI Selectable option (1 to 41)
It will load bit result of selected flag into PSI selected option.
Note: User should take care; below selectable options should be use either in In-built PLC or in PSI parameters
(C101 to C106 and C114, C115) at one time.
45. WRITE_PSO (OPCODE
049)
This command is used to write PSO status from In-built PLC to Inverter.
For this, user must have to select below PLC option in inverter parameters C107 to C113.
Example,
WRITE_PSO PSO (m) Fn
Where,
PSO (m) = PSO no. (1 to 7)
Fn = Flag no. (0 to 99)
WRITE_PSO
PSO
(C107 to C113)
FLAG NO
26:PLC O/P 1
BIT STATUS OF FLAG
27:PLC O/P 2
28:PLC O/P 3
29:PLC O/P 4
30:PLC O/P 5
31:PLC O/P 6
32:PLC O/P 7
