Axpert-Eazy AC Variable Frequency Drive
11.17
10
11
7. Description of Parameters
This description provides primary information of some parameters like Fault Codes, Status Codes
and Command Word properties. For more parameters details read the Operating manual of AC
Drive.
The access of parameter is not allowed until the valid password verification process is carried out.
Please check out 40107(B310) and 40108 (B309) for more details on “How to handle the password”.
40029 – 40078 & 40396 – 40435. Fault History Parameters (Mode- M, Group- 4)
0 No previous fault 70 IU-1 I-Unbalance Flt
11 Over Current 80 IU-2 I-Unbalance Flt
22 Drive Over Load 90 IU-3 I-Unbalance Flt
33 DC Bus Over Voltage 100 IU-4 I-Unbalance Flt
44 DC Bus Under Voltage 110 IU-5 I-Unbalance Flt
55 Adjustable Over Current 120 IU-1 Current Sensor Fail
66 Speed Deviation Fault 121 IU1V Current Sensor Fail
77 Output Phase Loss 122 IU1W Current Sensor Fail
88 Ground/ Earth Fault 123 IU1U Current Sensor Fail
99 Under Current 130 IU-2 Current Sensor Fail
111 Auto Tune Abnormal 131 IU2V Current Sensor Fail
222 Thermistor Over Temperature 132 IU2W Current Sensor Fail
333 External Trip 133 IU2U Current Sensor Fail
444 Over speed fault 140 IU-3 Current Sensor Fail
555 Comm. Loss (Digital Operation Panel) 141 U3V Current Sensor Fail
666 Eeprom Error 142 IU3W Current Sensor Fail
777 Emergency Stop 143 IU3U Current Sensor Fail
888 4-20mA Missing 150 IU-4 Current Sensor Fail
1111
U-p Current Sensor Fail 151 IU4V Current Sensor Fail
2222
Charging Fault 152 IU4W Current Sensor Fail
4444
Driver Fault 153 IU4U Current Sensor Fail
5555
Thermostat Over Temp 160 IU-5 Current Sensor Fail
6666
Thermistor Not Connected 161 IU5V Current Sensor Fail
8888
O/P Current Unbalance 162 IU5W Current Sensor Fail
10 IU-2 Temperature Flt 163 IU5U Current Sensor Fail
20 IU-3 Temperature Flt 190 V-p Current Sensor Fail
30 IU-4 Temperature Flt 200 W-p Current Sensor Fail
40 IU-5 Temperature Flt 271 IU-6 Temperature Flt
50 DU-1 Temperature Flt 272 IU-6 I-Unbalance Flt
60 DU-2 Temperature Flt 273 IU6U Current Sensor Fail
279 Ext Brake Ans Error 274 IU6V Current Sensor Fail
280 Thermostat Not Connected 275 IU6W Current Sensor Fail
281 Thermistor Short 278 Ext Brake RUN Error
277 Motor Over Load 282 Panel Temp Fault
