Axpert-Eazy AC Variable Frequency Drive
11.19
10
11
15 Over Speed Fault Reserved
IU-5 Current
Sensor Fail
Reserved Reserved
For example if the bit 0 of 40080 is 1 then the Thermistor Over Temperature fault has occurred.
40081– 40082. Status Codes
Access – Read Only
Resolution – 1
It contains information about current status of the system. It has bit level information.
Bit No
Status Code1 (40081)
Status Code2 (40082)
0 Normal Run Accel1/Accel2 (0/1)
1 Drive Stopped Start Delay
2 Acceleration Jogging
3 Deceleration Fault
4 Auto Tuning Auto Restart
5 Speed Search Auxiliary Drive
6 DC Breaking Emergency Stop
7 Motor Direction Password
8 Current Limit Factory Password
9 Power Off RUN
10 PLCT Contact Amtech
11 Voltage Limit KEB active
12 Torque Mode Reserved
13 Precharge Complete Reserved
14 Sleep mode Reserved
15 Auto Tune select Reserved
40110. Control Word
Access – Read/Write
Resolution – 1
It contains information about system configuration. It has bit level information.
Bit
No
Status
Description
WP
0 S Curve Selection
(A205)
This will enable the s-curve shape during acceleration
/deceleration.
= 0: Disable = 1: Enable
1 Ramp Down/Coast to
Stop (A304)
Select the stop method.
= 0: Ramp down to stop =1: Coast to stop
2 Motor Direction (A305) Select direction of motor rotation.
= 0: Forward = 1: Reverse
3 Auto Torque Boost
(A502)
When automatic torque boost is selected, the R1 drop
compensation and slip compensation functions will be valid.
= 0: Disable = 1: Enable
4 Open Phase Protection
(C307)
Output open-phase is detected if one phase current is <5%
and other two phase currents are >10% of motor rated
