MODE-B Parameters
B101
Rated Input
Voltage
Vac 3 1 5 1 Select suitable rated input voltage from the
below selections for 400V, 500V, 600V & 200V
Series.
=1: 380V
=4: 440V
=2: 400V
=5: 460V
=3: 415V
8 6 8 =6: 500V =7: 550V =8: 575V
11 9 11 =9: 600V =10: 660V =11: 690V
14 12 15 =12: 200V
=15: 240V
=13: 220V
=14: 230V
B102
Motor Voltage Vac 415 380 480 1 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting
value depends on the 400V, 500V, 600V or
200V Series model.
575 500 575
690 600 690
230 200 240
B103
Motor Current Amp M304 0.3*
M304
M304 0.1 Set the motor rated current from the motor
nameplate. It can be set to 30% of the AC
DRIVE rated current M304
B104
Motor Frequency Hz 50.0 10.0 600.0 0.1 Set the motor rated frequency from the motor
nameplate.
B105
Motor Speed rpm 1500 1 36000 1 Set the motor rated RPM from the motor
nameplate.
B106
Motor Output
Rating
kW M305 0.1 1500.0
0.1 The motor’s rated output at base speed is set.
B107
Motor Poles 4 2 16 2 Insert the motor poles.
B108
No Load Output
Voltage
Vac 160 20 480 1 The terminal voltage at no load at the base
speed is set.
B109
Encoder Pulses P/R 1024 60 10000 1 Set as per the encoder specification.
B110
Carrier Frequency kHz 5 2 10 1 This parameter sets the AC DRIVE carrier
frequency.
4 6 For 315kW and higher models in 400V series
and for all models of 500V/600V series.
B111
DTC Gain 70 0 255 1 This is gain for the dead time compensation.
Adjust incase of motor hunting.
B112
kW without VFD kW M305 0 65535 1 Enter previous kW consumption without VFD.
This parameter is used to calculate the energy
saving using VFD.
B113
Currency Selection
1 1 3 1 Select your currency for the energy cost.
=1: INR
=2: USD
=3: EURO
B114
Energy Cost 4.000 0.000
65.535
0.001 Enter here the cost per kW in selected currency.
B115
Local Set Voltage % 100.0 5.0 100.0 0.1 This is the set voltage when the inverter is used
as variable voltage source application and
voltage reference in B116 is selected as Local.
Set as % of motor voltage B103.
B116
Output Voltage
Reference
Selection
1 1 3 1 Select the set reference for the output voltage,
when inverter is used as variabl
application.
=1: Local
=2: FSV 0-10V
=3: FSI 4-20mA
To Next Page
