Amtech
6-18
6
C206
Vout-2 Gain 1.000
0.100
2.500 0.001 This is gain setting for the VO2 analog output.
C207
Iout-1 Gain 1.000
0.100
2.500 0.001 This is gain setting for the IO1 analog output.
C208
Iout-1 Bias 1000 100 1500 1 This is bias setting for the IO1 analog output.
C209
Iout-2 Gain 1.000
0.100
2.500 0.001 This is gain setting for the IO2 analog output.
C210
Iout-2 Bias 1000 100 1500 1 This is bias setting for the IO2 analog output.
C211
FSV Gain
1.000
0.100
1.500
0.001
This is gain setting for the FSV analog input.
C212
FSV Bias
100
0
1000
1
This is bias setting for the FSV analog input.
C213
FSI Gain
1.000
0.100
1.500
0.001
This is gain setting for the FSI analog input.
C214
FSI Bias
1000
0
1500
1
This is bias setting for the FSI analog input.
C215
VIN Gain
1.000
0.100
1.500
0.001
This is gain setting for the VIN analog input.
C216
VIN Bias
100
0
1000
1
This is bias setting for the VIN analog input.
C217
IIN Gain
1.000
0.100
1.500
0.001
This is gain setting for the IIN analog input.
C218
IIN Bias
1000
0
1500
1
This is bias setting for the IIN analog input.
C219
FSV/FSI Time
Constant
mS 100 0 1000 1 This parameter set the filter time constant for
the FSV and FSI analog inputs.
C220
VIN/IIN Time
Constant
mS 100 0 1000 1 This parameter set the filter time constant for
the VIN and IIN analog inputs.
C221
Vout-1 Bias 100 0 1000 1 This is bias setting for analog output voltage
VO1.
C222
Vout-2 Bias 100 0 1000 1 This is bias setting for analog output voltage
VO2.
C223
Input voltage gain 1.000
0.100
2.000 0.001 This parameter sets the gain for VRY (M201)
and VYB (M202) monitor.
3: STATUS OUTPUT DETECTION LEVEL
C301
Frequency
Attainment
Detection Width
% 1.0 0.0 20.0 0.1
The attained frequency output (Freq Attain)
operation width is set.
C302
I-Detection Level
(current detection)
% 100.0
5.0 200.0 0.1
The current detection (I-Detection) operation
level is set. Set with a percentage of the rated
current (B103). The hysteresis will occur with
set value in parameter C314 for the I-Detection
operation.
C303
Speed Detection
Level-1
% 95.0 1.0 105.0 0.1 The speed detection operation level is set. Set
with a percentage to the max frequency A103.
The output frequency or the motor speed will be
the comparison target. A 1% hysteresis will
occur with speed detection operation.
C304
Speed Detection
Level-2
% 50.0 1.0 105.0 0.1
C305
Zero Speed
Detection Level
% 1.0 0.0 50.0 0.1 The Zero speed detection operation level is set.
Set with a percentage to the max frequency
(A103). The output frequency or the motor
speed will be the comparison target. A 1%
hysteresis will occur with zero speed operation.
C306
4-20mA Refe
Loss
2 1 7 1 This parameter configures the AC DRIVE’s
response to a failure of 4-20mA Frequency
reference input signal.
=1: No action at fault detection
=2: Minor fault alarm & run at minimum speed
=3: Minor fault alarm & run at maximum speed
=4: Minor fault alarm & run at set speed
=5: Minor fault alarm & run at preset speed-1
=6: Fault, ramp down to stop
=7: Fault, coast to stop
