Amtech Axpert-Eazy Series - Page 76

Amtech
6-30
6
MODE-G: Pattern Run Function Parameters
No.
Parameter
Unit
Def
Min
Max
Res
Description
WP
GROUP
-
1: MODE SELECTION FOR PATTERN RUN TABLE
-
1
G101 PR Mode T1-STP1 1 1 3 1 Select the required mode for pattern run
function for each step of Table-1
G102 PR Mode T1-STP2 1 1 3 1
G103 PR Mode T1-STP3 1 1 3 1 =1: STOP
G104 PR Mode T1-STP4 1 1 3 1 =2: FORWARD
G105 PR Mode T1-STP5 1 1 3 1 =3: REVERSE
G106 PR Mode T1-STP6 1 1 3 1
G107 PR Mode T1-STP7 1 1 3 1
G108 PR Mode T1-STP8 1 1 3 1
G109 PR Mode T1-STP9 1 1 3 1
G110 PR Mode T1-
STP10
1 1 3 1
G111 PR Mode T1-
STP11
1 1 3 1
G112 PR Mode T1-
STP12
1 1 3 1
G113 PR Mode T1-
STP13
1 1 3 1
G114 PR Mode T1-
STP14
1 1 3 1
G115 PR Mode T1-
STP15
1 1 3 1
GROUP
-
2: MODE
SELECTION
FOR PATTERN RUN TABLE
-
2
G201 PR Mode T2-STP1 1 1 3 1
Select the required mode for pattern run
function for each step of Table-2
G202 PR Mode T2-STP2 1 1 3 1
G203 PR Mode T2-STP3 1 1 3 1 =1: STOP
G204 PR Mode T2-STP4 1 1 3 1 =2: FORWARD
G205 PR Mode T2-STP5 1 1 3 1 =3: REVERSE
G206 PR Mode T2-STP6 1 1 3 1
G207 PR Mode T2-STP7 1 1 3 1
G208 PR Mode T2-STP8 1 1 3 1
G209 PR Mode T2-STP9 1 1 3 1
G210 PR Mode T2-
STP10
1 1 3 1
G211 PR Mode T2-
STP11
1 1 3 1
G212 PR Mode T2-
STP12
1 1 3 1
G213 PR Mode T2-
STP13
1 1 3 1
G214 PR Mode T2-
STP14
1 1 3 1
G215 PR Mode T2-
STP15
1 1 3 1
