GROUP-2
M201: Input Voltage Vry (Vac)
This parameter displays the input line-to-line voltage between R & Y at input. This is calculated based
on the DC bus voltage and output power. This may differ from the actual input voltage. If this voltage
differs from the actual voltage then adjust parameter C223: Input voltage gain. When selected for the
normal parameter display in A601~A608, the value will be displayed with “Vry” unit.
M202: Input Voltage Vyb (Vac)
This parameter displays the input line-to-line voltage between Y & B at input. This is calculated based
on the DC bus voltage and output power. This may differ from the actual input voltage. If this voltage
differs from the actual voltage then adjust parameter C223: Input voltage gain. When selected for the
normal parameter display in A601~A608, the value will be displayed with “Vyb” unit.
M203: Output Voltage (Vac)
This parameter displays the output line-to-line voltage. This is calculated voltage based on the voltage
command. This may differ from the actual output voltage. The actual output voltage depends on input
supply voltage. When the AC DRIVE is stop, it will display zero. When auxiliary drive is selected, it
displays the output voltage for the auxiliary drive.
When selected for the normal parameter display in A601~A608, the value will be displayed with “Vo”
unit.
M204: DC Bus Voltage (Vdc)
This parameter displays the dc bus voltage. When selected for the normal parameter display in
A601~A608, the value will be displayed with “Vdc” unit.
M205: Output Power (kW)
This parameter displays the output power. This may differ from the actual output power. When the AC
DRIVE is stop, it will display zero. When the auxiliary drive is selected, the output power of auxiliary
drive is displayed.
When selected for the normal parameter display in A601~A608, the value will be displayed with “kW”
unit.
M206: Energy Meter (kWH)
M207: Energy Meter (MWH)
This parameter displays the total output power consumption per hour basis. This may differ from the
actually consumed output energy. This is stored in the non-volatile memory.
When selected for the normal parameter display in A601~A608, the value will be displayed with
“kWH” and “MWH” unit respectively.
M208: Heat sink Temperature (°C)
This parameter displays the actual heat sink temperature. When selected for the normal parameter
display in A601~A608, the value will be displayed with “°C” unit.
M209: Torque Current (%)
The torque current value is displayed using the motor rated current B103 as 100%. When the AC
DRIVE is stop, it will display zero.
