AMX Precis LT User Manual

Standard Video & Stereo Models
Applicability Notice
This chapter contains specific information for the following Precis
LT
Models.*
Standard Video & Stereo (5-Term)
Front Control Panel Blank Panel
4x4 P37-0404-115 4x4 37-96
4x8 P37-0408-115 4x8 37-99
8x4 P37-0804-115 8x4 37-02
8x8 P37-0808-115 8x8 37-05
* The Standard Video and Stereo Model comes in a variety of configurations. For
information on model configurations not listed, contact your authorized AutoPatch
Dealer.
Overview
Standard Video and Stereo Models can route audio and video signals simultaneously
or separately. For information on levels and control, see Control Panel Operations
on page 32 or BCS Serial Control Protocol on page 40.
The Standard Video and Stereo Models have BNC connectors (see page 8) for
routing composite video signals. They also have 5-Term stereo audio connectors (see
pages 11-12) to route audio, either balanced or unbalanced depending on the wiring.
Standard Video & Stereo Models 18
