Overview
Component Video and Stereo Models can route audio and video signals
simultaneously or separately. For information on levels and control, see Control
Panel Operations on page 32 or BCS Serial Control Protocol on page 40.
The Precis
LT
Component Video and Stereo Models have two connector options.
In one option, BNC connectors (see page 8) route component video signals and
5-Term stereo audio connectors route either balanced or unbalanced audio,
depending on wiring. For information on audio wiring, see pages 11-12. In the
second option, RCA jacks (see page 13) route both component video and unbalanced
stereo audio signals.
Video Routing Options
Both models can be cabled to route any one of the following video signals over each
input or output:
ä
Three component RGsB video signals (attach cables to all three of the video
connectors)
ä
Three component Y/Pb/Pr video signals (attach cables to all three of the video
connectors
ä
Y/c signals (attach cables to the top two video connectors)
ä
A single composite signal (attach cable to the bottom video connector)
Note: The Precis
LT
cannot route Y/c and composite signals or more than one
composite signal for a single input or output.
25 Component Video & Stereo Models
Component Video & Stereo Overview
