AMX Precis LT User Manual

S-Video & Stereo Models
Applicability Notice
This chapter contains specific information for the following Precis
LT
Models.*
S-Video & Stereo (5-Term)
Front Control Panel Blank Panel
4x4 P37-0404-615 4x4 37-08
4x8 P37-0408-615 4x8 37-11
8x4 P37-0804-615 8x4 37-14
8x8 P37-0808-615 8x8 37-17
* The S-Video and Stereo Model comes in a variety of configurations. For
information on model configurations not listed, contact your authorized AutoPatch
Dealer.
Overview
S-Video and Stereo Models can route audio and video signals simultaneously or
separately. For information on levels and control, see Control Panel Operations on
page 32 or BCS Serial Control Protocol on page 40.
The S-Video and Stereo Models have locking S-Video connectors (see page 8) for
routing S-Video signals and 5-Term stereo audio connectors (see pages 11-12) for
routing balanced or unbalanced audio, depending on the wiring.
S-Video & Stereo Models 21

AMX Precis LT Specifications

General

Brand	AMX
Model	Precis LT
Category	Matrix Switcher
Language	English
