AMX Precis LT User Manual

Parameter Conditions Value
S- Video
Input
Level (max.) +/-1.9 V
Impedance 75 ohms
Return Loss f = 5 MHz <-35 dB
Connector Type
S-Video/
Locking S-Video
S- Video
Output
Level (max.) +/-1.9 V
Impedance 75 ohms
Return Loss f = 5 MHz <-35 dB
Connector Type
S-Video/
Locking S-Video
Parameter Conditions Value
Stereo Audio
Throughput
Frequency Response f = 20 Hz to 20 KHz <+/-0.1 dB
THD + Noise
f=20Hzto20KHz
Vin = -10 to +14 dB
<0.025%
Crosstalk (adjacent
channel)
f = 1kHz, Vin = +2 dBu <-105 dB
Channel Separation f = 1kHz, Vin = +2 dBu >-105 dB
Signal to Noise Ratio
(SNR)
f=20Hzto20kHz
Vin = +14 dBu
>105 dB
CMRR f = 20 Hz to 20 kHz >80 dB
Stereo Audio
Input
Level (max.)
+14 dBu,
balanced
Impedance 18 kohms
Gain Adjustment Range
Potentiometer
adjustment
+6 dB to -6 dB
Type
Balanced or
unbalanced
Connector Type
Pluggable
5-position
terminal block
Stereo Audio
Output
Level (max.)
+14 dBu,
balanced
Impedance 50 ohms
Type
Balanced or
unbalanced
Connector Type
Pluggable
5-position
terminal block
