AMX Precis LT User Manual

Parameter Conditions Value
Component
Video
Throughput
Frequency
Response
1toAll
+/-3 dB to 300 MHz or better
+/-1.5 dB to 100 MHz or better
Differential Gain*
f = 3.58 MHz
10 to 90% APL
<0.2% or better
Differential
Phase*
f = 3.58 MHz
10 to 90% APL
<0.2° or better
Crosstalk
(adjacent
channel)
f=5MHz
f=30MHz
f = 150 MHz
<-70 dB
<-60 dB
<-35 dB
Signal to Noise
Ratio (SNR)
Vin = 0.7 V,
100% IRE
>65 dB
* Differential gain and phase measurements are preformed with a standard 5-step modulated staircase
test signal.
Parameter Conditions Value
Component
Video
Input
Level (max.)
+/-1.5 V
Impedance 75 ohms
Return Loss
(BNC)
f = 5 MHz <-45 dB
Return Loss
(RCA)
f = 5 MHz <-42 dB
Connector Types
BNC & RCA
Component
Video
Output
Level (max.)
+/-1.5 V
Impedance 75 ohms
Connector Types BNC & RCA
Parameter Conditions
Value
Stereo Audio
Throughput
Frequency
Response
f=20Hzto20
KHz
<+/-0.1dB
THD + Noise
f=20Hzto20
KHz
Vin = -10 to +14 dB
<0.025%
Crosstalk
(adjacent
channel)
f=1kHz
Vin = +2 dBu
<-105 dB
Signal to Noise
Ratio (SNR)
f=20Hzto20kHz
Vin = +14 dBu
>105 dB
CMRR f = 20 Hz to 20 kHz >80 dB
Connector Types
Pluggable 5-position terminal
block & RCA
Component Video & Stereo Product Specifications
27 Component Video & Stereo Models
