AMX Precis LT

Parameter Conditions Value
Video
Input
Level (RGB) (max.) +/-1.5 V
Impedance (RGB) 75 ohms
Level (HV) (max.) +/-5 V
Impedance (HV) 22 kohms
Return Loss f = 5 MHz <-42 dB
Connector Type HD-15
Video
Output
Level (RGB) (max.) +/-1.5 V
Impedance (RGB) 75 ohms
Level (HV) Follows input +/-5 V
Impedance (HV) 75 ohms
Connector Type HD-15
Parameter Conditions Value
Stereo Audio,
Unbalanced
Throughput
Frequency Response f = 20 Hz to 20 KHz <+/-0.1 dB
THD + Noise
f=20Hzto20KHz
Vin = -10 to +14 dB
<0.025%
Crosstalk (adjacent
channel)
f = 1kHz, Vin = +2 dBu <-105 dB
Signal to Noise Ratio
(SNR)
f=20Hzto20kHz
Vin = +14 dBu
>105 dB
Stereo Audio,
Unbalanced
Input
Level (max.)
+14 dBu,
unbalanced
Impedance 18 kohms
Gain Adjustment
Range
Potentiometer
adjustment
+6 dB to -6 dB
Type
Unbalanced
Connector Type
Pluggable
3-position terminal
block
Stereo Audio,
Unbalanced
Output
Level (max.)
+14 dBu,
unbalanced
Type
Unbalanced
Impedance 50 ohms
Connector Type
Pluggable
3-position terminal
block
AutoPatch reserves the right to modify its products and their specifications without notice.
RGBHV/HD-15 & Stereo Models 31
