Kp, proportional gain, 35
L
lag matching, description, 35
LED
amplifier, table, AC systems, 28
defined, 28
LED fault conditions
1 LED, servo amplifier, table, DC
systems, 15
5 LEDs, servo amplifier, table, DC
systems, 15
light emitting diode. See LED
linear scales, index pulse, 7
LOOP GAIN pot, description, DC
systems, 13
Low Speed Electronic Circuit
Breaker. See LS/ECB
LS/ECB fault, causes listed, DC
systems, 16
M
Manual (F4), 3, 7
Manual (F4), DC systems, 19
Manual Data Input. See MDI
MDI
activate, 3
activating, 7
cancel, 3
canceling, active, 7
rigid tapping test, 30
MDI (F5), 3, 7
menus, Tuning Setup Menu,
illustration, 34
message area, illustration, 2
message, clearing, 4
Misc (F9), 3
Misc (F9), AC systems, 28
miscellaneous tests
(F9), AC systems, 28
amplifier test link, AC systems, 32
backup amp settings, AC systems, 33
backup file, description, AC systems, 33
CanBus Test, AC systems, 29
description, AC systems, AC systems, 28
restore from backup, AC systems, 33
rigid tapping test, description, 30
save amp settings, AC systems, 32
monitor, amplifier test link,
description, AC systems, 32
motion control axes, balancing, 8
Motion Setup/Testing. See MST
MotionMaestro, AC systems, 33
MST
accessing, utility, 1
activating, screen, 2
defined, 1
description, 1
screen areas, descriptions, 2
screen areas, illustration, 2
screen, exiting, 37
soft keys, listed, 3
utility, to activate, 1
O
over temp fault, causes listed,
DC systems, 17
over voltage fault, causes listed,
DC systems, 17
P
P/N 70000499, 3000M CNC
Setup Utility Manual,
referenced, 4, 37
password, entering, 4
PID
controller, 30
defined, 1
tuning, 1
pop-up menu, miscellaneous
tests, AC systems, 28
prompt area, illustration, 2
prompt field, clearing, 4
proportional
gain, Kp, 35
integral derivative. See PID
R
ResChk (F2), 3, 5
reset amplifier, miscellaneous
tests, description, AC systems,
33
resetting, amplifier fault, DC
systems, 17
restore from backup
amp parameters, description, AC
systems, 33
procedure, AC systems, 23
rigid tapping test
miscellaneous tests, description, 30
not optimally tuned, illustration, 31
optimally tuned, illustration, 31
