Centering the Workpiece
This feature allows you to quickly locate the centerline of the workpiece on each axis.
Example: To locate the centerline of the workpiece on an axis:
1. Zero the display at one edge of the workpiece.
2. Move to the opposite edge of the workpiece and touch the other edge.
3. Press
4. Press the desired axis key to select the axis.
5. Move toward the center of the workpiece until the axis display indicates 0 (zero).
This is the centerline of the workpiece on the axis.
NOTE:
The DRO compensates for the tool width.
